Building Integrated Intelligent EnergyStation（BIE-STATION）

BIE-STATION

The English is derived from the standard name of our product (Building Integrated Intelligent EnergyStation), "B" is Building, "I" is Integrated and Intelligent, and "E" is Energy.

The Chinese interpretation of the station: the call will come (our products are integrated assembly, transported to the site can be installed, the response admonition is very fast), come to the station (come to play a role in the battle, the characteristics of the assembly refrigeration station), the station will win (product quality is good, can fully meet the requirements, confidence).

Features

Talking to us

Product Core Advantages

BIE-STATION has the advantages of "easy movement", "easy disassembly" and "parallel splicing of cold coverage".

20%

Comprehensive
energy saving rate
of 20% or more
15%

Save 15%
material depletion
20%

Save more than 20%
on initial investment costs
80%

80% reduction in
site construction cycle time
1/3

Save 1/3 of the
server room space
Reduce carbon emissions

Intelligent control
reduces post-operations and maintenance costs

Product Specifications

Product parameters
Product option table

Basic parameters of cold source module
Spec.	Cooling Capacity	CHW Flowrate	CHW Pipe size	CW Flowrate	CW Pipe size	Pump Head				Total Power Capacity	Dimension (LWH)	Operate Weight
	Cooling Capacity	CHW Flowrate	CHW Pipe size	CW Flowrate	CW Pipe size	(m)CHW		(m)CW		Total Power Capacity	Dimension (LWH)	Operate Weight
	kW	CMH	DN	CMH	DN	Min.	Max	Min.	Max	kW	mm	Ton
HXM50	176	30	80	38	80	20	45	15	30	44	600024382896	10
HXM100	364	63	100	78	100					89	800035003000	13
HXM200	705	121	150	152	150					156	800035003000	14
HXM310	1073	185	150	231	200					228	1000035003500	21
HXM400	1406	241	200	285	200					305	1000035003500	25
HXM500	1775	302	200	357	200					448	1200035003500	26
HXM600	2110	362	250	428	250					546	1200035003500	28
HXM700	2461	453	250	536	250					651	1200035003500	30
HXM800	2813	483	250	571	250					713	1200035003500	33
HXM900	3164	543	250	644	250					763	1400040003500	37
HXM1000	3516	604	300	712	300					815	1400040003500	41

Option Table
Equipment	Standard	Optional	Remark
Chiller	✓		Centrifugal/Screw/ Magnetic bearing
Chilled Water Pump	✓		IE3/IE4
Cooling Water Pump	✓		IE3/IE4
Cooling Tower	✓		Closed/Open system
Constant Pressure Unit		✓
Chemical Dosing Unit		✓
Side Stream Unit		✓
MCC	✓		Constant Frequency/VSD
Manual Valve	✓		SS/CS
Motorized Valve, Temp & Pressure transducer		✓
BMS		✓
Lighting, HVAC and other Interior parts	✓
